Chipset

Image Sensor

1/2.7” HD CMOS

Main processor

Mstar327E

Resolution

4MP

Effective Pixels

  2688(H)*1520(V)

Compression

H.265/H.264/JPEG/AVI/ MJPEG

TV System

PAL/NTSC Adjustable

Electronic Shutter Time

Auto: PAL 1/25-1/10000Sec; NTSC 1/25-1/10000Sec

S/N Ratio

≥52Db

Scanning System

Progressive

Lens

Focus Length

2.8mm (110°Wide-angle)

Focus Control

Fixed

Lens Type

Fixed

Pixels

4MP

Night Vision

Infrared LED

6pcs IR   Leds + 2pcs White Leds

Infrared Distance

12M

IR Status

Under 10 Lux By CDS

IR Power On

CDS Auto Control

Network

WIFI

2.4GHz WiFi (IEEE 802.11 b/g/n)

P2P

YES

Protocol

TCP/IP,UDP/IP,DHCP,RTMP,MUTP

IP Add

Support Dynamic IP Address

OS Require

IOS (V10.0 or Above) or Android (V5.0 or Above)

SD Card

Support Max 128GB TF-card

Cloud Storage

Yes, 7 days or 1G for Free, Auto Coverage

Audio Input

Internal Microphone (38Db)

Pickup Range

5 Meters

Audio Output

Internal Speaker (38Db)

Audio Type

Two-way Audio with Noise Cancellation

Video Quality

2688*1520@20fps

Video Mode

Manual Video, Alarm Trigger Video

Smart Phone

iPhone, Android

Smart AI Function

Intelligent Recognition

Humanoid   Recognition + Vehicle Recognition + Pet Recognition + Parcel Detection

Smart PIR Detection

Wide-Angle Planar PIR Detection + Support Particular   Area Detection

Alarm Notification

Video Alarm Push by APP + White Light Flashing + Alarm   Sounds

Camera Features

Day/Night

Color/ B&W (Auto ICR )

BLC

Support

AGC

 Support

WDR

Support

Working   Time

8   Months (Supposed there are 20 of video records per day)

Standby   Time

1   Year

Device Wakeup Time

Within 600ms

General

Housing

IP65

Bracket

Magnet and 1/4 universal screw holes

Operation Temperature

-10℃ ~ +45℃ RH95% Max

Storage Temperature

-20℃ ~ +60℃ RH95% Max

Power Type

2x #21700 non-removable Tesla Battery, 10000mAh; DC5V

Charge Time

8 Hours

Consumption

Working Mode: 170mA Standby Mode: 200μA

Package Dimension

162(L)*122(W)*82(H)mm

Total Weight

570g
