Chipset

Image Sensor

1/2.7” HD CMOS

Main processor

HI3516C

Resolution

1080P

Effective Pixels

  1920(H)*1080(V)

Compression

H.264/JPEG/AVI/ MJPEG

TV System

PAL/NTSC Adjustable

Electronic Shutter Time

Auto: PAL 1/25-1/10000Sec; NTSC 1/25-1/10000Sec

S/N Ratio

≥52Db

Scanning System

Progressive

Lens

Focus Length

2.8mm (130°Wide-angle)

Focus Control

Fixed

Lens Type

Fixed

Pixels

2MP

Night Vision

Infrared LED

IR LED: F8*6pcs   (850nm)

Infrared Distance

8M

IR Status

Under 10 Lux By CDS

IR Power On

CDS Auto Control

Network

WIFI

2.4GHz WiFi (IEEE 802.11 b/g/n)

P2P

YES

Red LED Blink

Power OK, Waiting for WiFi Connection

Blue & Red Blink

WiFi Setting Succeed, Waitting for APP   Connection

Blue LED Blink

Power & Network OK, Device in Working   Status

LED OFF

No Power / StandBy Mode

OS Require

Ios (V10.0 or Above) or Android (V5.0 or   Above)

SD Card

                                                        Support Max 64GB TF-card

Cloud Storage

                                                              Yes

Audio Input

Internal Microphone (38dB)

Pickup Range

5 Meters

Audio Output

Internal Speaker (38dB)

Audio Type

Two-way Audio with Noise Cancellation

Video Quality

1920*1080@25fps

Video Mode

Manual Video; Alarm Video

Smart Phone

iPhone, Android

Camera Features

Day/Night

Color/ B&W (Auto ICR )

BLC

Support

AGC

 Support

WDR

Support

Motion Detection

Smart PIR Sensor (Sensitivity Editable)

Device Wakeup Time

Within 600ms

General

Housing

IP65

Bracket

YES

Operation Temperature

-20℃ ~ +55℃ RH95% Max

Storage Temperature

-25℃ ~ +60℃ RH95% Max

Power Type

2x #18650 Battery

Consumption

Working Mode: 170mA Standby Mode: 200μA

Dimension

85(L)*55(W)*90(H)mm

Weight

300g
