Chipset

Image Sensor

1/2.7" SC3235

Main processor

HI3518EV300

Resolution

3 MP

Effective Pixels

  2560 (H)*1440(V)

Compression

H.264/JPEG/AVI/ MJPEG

TV System

Lite OS

Pan

0~355°

Tilt

0~120°

S/N Ratio

≥52Db

Lens

Focus Length

3.6mm

Focus Control

Fixed

Lens Type

Fixed

Pixels

3 MP

Night Vision

Infrared LED

6pcs IR   Led+6pcs White Led (B&W/ Colorful Optional)

Infrared Distance

40 M

IR Status

Under 10 Lux By CDS

IR Power On

CDS Auto Control

Network

4G

4G Mode: FDD-LTE,TDD-LTE,TD-SCDMA,HSPA+,HSUPA,UMTS,EVDO,EDGE,GPRS,GSM,CDMA1X

RJ45 Access

N/A

IE Protocol

P2P, TCP/IP, HTTP, TCP, UDP, SMTP, FTP, DHCP, DNS,   DDNS, NTP, UpnP, RTSP

Antenna

2x Strong   Antenna 1.5db

P2P

TUYA Smart Life

SD Card

Support Max 128GB Micro SD-card

Cloud Storage

                                                                                             YES

Audio Input

Internal Microphone (38dB)

Pickup Range

5 Meters

Audio Output

Internal Speaker (38dB)

Audio Type

AAC,G726,G711,MP3; Two-way Audio with Noise   Cancellation

Video Quality

12560*1440@20fps

Video Mode

Manual Video Recording; Alarm Video Recording

Smart Phone

Android 2.3 and above; IOS7.0 and above

Camera Features

Day/Night

Full Color / B&W Optional

BLC

Support

AGC

 Support

Motion Detection

Smart PIR Sensor (Sensitivity Editable)

Panoramic Show

Analog 3D & Auto Cruise

Voice Call

YES

Remote Waking

YES

Motion Waking

YES

General

Housing

Metal  for   outdoor Use, IP66 Waterproof

Bracket

YES

Operation Temperature

-20℃ ~ +55℃ RH95% Max

Storage Temperature

-25℃ ~ +60℃ RH95% Max

Power Type

4x #21700 Battery (4*4800Ma=192000mA) / DC 5-8V

Dimension

290(L)*180(W)*150(H)mm

Weight

1800g
