Chipset

Image Sensor

1/2.7" PS5230

Main processor

HI3518E

Resolution

1080P

Effective Pixels

  1920(H)*1080(V)

Compression

H.264/JPEG/AVI/ MJPEG

TV System

Lite OS

Pan

N/A

Tilt

N/A

S/N Ratio

≥52Db

Lens

Focus Length

3.6mm

Focus Control

Fixed

Lens Type

Fixed

Pixels

2MP

Night Vision

Infrared LED

8pcs   850NM IR Leds

Infrared Distance

10-15M

IR Status

Under 10 Lux By CDS

IR Power On

CDS Auto Control

Network

WIFI

2.4GHz WiFi (IEEE 802.11 b/g/n)

RJ45 Access

N/A

ONVIF

N/A

Antenna

1x   Strong Antenna 1.5db

P2P

YES

SD Card

Support Max 64GB Micro SD-card

Cloud Storage

YES

Audio Input

Internal Microphone (38dB)

Pickup Range

5 Meters

Audio Output

Internal Speaker (38dB)

Audio Type

AAC,G726,G711,MP3; Two-way Audio with Noise   Cancellation

Video Quality

1920*1080@25fps / 640*360@30fps

Video Mode

Manual Video Recording; Alarm Video   Recording

Smart Phone

Android 5.0 and above; IOS10.0 and above

Camera Features

Day/Night

Color/ B&W (Auto ICR )

BLC

Support

AGC

 Support

Motion Detection

Smart PIR Sensor (Sensitivity Editable)

Panoramic Show

Analog 3D & Auto Cruise

Voice Call

YES

Remote Waking

YES

Motion Waking

YES

General

Housing

Metal    for outdoor Use, IP66 Waterproof

Bracket

YES

Operation Temperature

-15℃ ~ +55℃ RH95% Max

Storage Temperature

-20℃ ~ +60℃ RH95% Max

Power Type

2X #18650 Battery/ Rechargeable by Solar   Power

Dimension

220(L)*80(W)*70(H)mm

Weight

840g
