Chipset

Image Sensor

1/2.7" SC2235H

Main processor

HI3518E

Resolution

1080P

Effective Pixels

  1920(H)*1080(V)

Compression

H.264/JPEG/AVI/ MJPEG

TV System

Lite OS

Pan

0~355°

Tilt

0~90°

S/N Ratio

≥52Db

Lens

Focus Length

3.6mm

Focus Control

Fixed

Lens Type

Fixed

Pixels

2MP

Night Vision

Infrared LED

4pcs White   Led +2pcs IR Array

Infrared Distance

30M

IR Status

Under 10 Lux By CDS

IR Power On

CDS Auto Control

Network

4G Mode

FDD-LTE,TDD-LTE,TD-SCDMA,HSPA+,HSUPA,UMTS,EVDO,EDGE,GPRS,GSM,CDMA1X

WIFI(AP Hot)

LTE WIFI Communication Mode

IE Protocol

P2P, TCP/IP, HTTP, TCP, UDP, SMTP, FTP,   DHCP, DNS, DDNS, NTP, UpnP, RTSP

Antenna

2x Strong   Antenna 1.5db

P2P

YES

SD Card

Support Max 128GB Micro SD-card

Cloud Storage

                                                                    YES

Audio Input

Internal Microphone (38dB)

Pickup Range

5 Meters

Audio Output

Internal Speaker (38dB)

Audio Type

AAC,G726,G711,MP3; Two-way Audio with Noise   Cancellation

Video Quality

1920*1080@25fps

Video Mode

Manual Video Recording; Alarm Video   Recording

Smart Phone

Android 2.3 and above; IOS7.0 and above

Camera Features

Day/Night

Color/ B&W (Auto ICR )

BLC

Support

AGC

 Support

Motion Detection

Smart PIR Sensor (Sensitivity Editable)

Panoramic Show

Analog 3D & Auto Cruise

Voice Call

YES

Remote Waking

YES

Motion Waking

YES

General

Housing

Metal    for outdoor Use, IP66 Waterproof

Bracket

YES

Operation Temperature

-20℃ ~ +55℃ RH95% Max

Storage Temperature

-25℃ ~ +60℃ RH95% Max

Power Type

6x #18650 Battery/ DC 5-8V

Dimension

287(L)*205(W)*175(H)mm

Weight

2000g
