Chipset

Image Sensor

1/3” SC1145

1/3” GMAX0806

Main processor

FH8810

FH8630

Resolution

960P

1080P

Effective Pixels

 1280(H)*960(V)

  1920(H)*1080(V)

Compression

H.264/JPEG/AVI/MJPEG

H.264/JPEG/AVI/ MJPEG

TV System

PAL/NTSC Adjustable

Pan

0°-355°

Tilt

0°-100°

S/N Ratio

≥52Db

Lens

Focus Length

1.44mm(185°)

3.6mm(185°)

Focus Control

Fixed

Fixed

Lens Type

Fixed

Fixed

Pixels

1.3MP

2MP

Night Vision

Infrared LED

4pcs Red   Light + 3 pcs IR Array

Infrared Distance

10M

IR Status

Under 10 Lux By CDS

IR Power On

CDS Auto Control

Network

WIFI

2.4GHz WiFi (IEEE 802.11 b/g/n)

RJ45 Access

Yes

IE Protocol

HTTP/TCP/IP/RTSP/ONVIF

Antenna

2x Strong   Antenna 1.5db（Internal）

P2P

YES

OS Require

iOS (V10.0 or Above) or Android (V5.0 or   Above)

SD Card

                                                        Support Max 64GB TF-card

Cloud Storage

                                                                    YES

Audio Input

Internal Microphone (38dB)

Pickup Range

5 Meters

Audio Output

Internal Speaker (38dB)

Audio Type

Two-way Audio with Noise Cancellation

Video Quality

1280*960@25fps

1920*1080@25fps

Video Mode

Manual Video; Alarm Video

Alarm Mode

Audible & Visual Alarm (Red lighting +   Alarm Sound)

Smart Phone

iPhone, Android

Camera Features

Day/Night

Color/ B&W (Auto ICR )

BLC

Support

Support

AGC

Support

 Support

Motion Detection

Smart PIR Sensor (Sensitivity Editable)

General

Housing

Plastic for Indoor Use

Bracket

YES

Operation Temperature

-20℃ ~ +55℃ RH95% Max

Storage Temperature

-25℃ ~ +60℃ RH95% Max

Power Type

DC 12V 750mA

Dimension

160(L)*160(W)*140(H)mm

Weight

400g
