Chipset

Image Sensor

1/3” AK3918E

1/3" RTS3901

1/3" RTS3901

1/3" FH8330

Main processor

SC1035

SC2035

SC3035

SC5035

Resolution

960P

2 MP

3 MP

4 MP

Effective Pixels

 1280(H)*960(V)

  1920(H)*1080(V)

  1536(H)*1536(V)

2688(H)*1520(V)

Compression

H.264/JPEG/AVI/MJPEG

H.264/JPEG/AVI/ MJPEG

H.264/JPEG/AVI/ MJPEG

H.264/JPEG/AVI/ MJPEG

TV System

PAL/NTSC Adjustable

Electronic   PTZ

Yes

Lens

Focus Length

1.14mm Fisheye

1.14mm Fisheye

1.14mm Fisheye

1.14mm Fisheye

Focus Control

Fixed

Fixed

Fixed

Fixed

Lens Type

Fixed

Fixed

Fixed

Fixed

Pixels

1.3MP

2MP

3MP

4MP

Night Vision

Infrared LED

IR LED: 3pcs   IR Array /White LED Optional

Infrared Distance

15M

IR Status

Under 10 Lux By CDS

IR Power On

CDS Auto Control

Network

WIFI

2.4GHz WiFi (IEEE 802.11 b/g/n)

Wire RJ45 Cable

Optional

P2P

YES

OS Require

iOS (V10.0 or Above) or Android (V5.0 or   Above)

SD Card

                                                        Support Max 64GB TF-card

Audio Input

Internal Microphone (38dB)

Pickup Range

5 Meters

Audio Output

Internal Speaker (38dB)

Audio Type

Two-way Audio with Noise Cancellation

Video Quality

1280*960@25fps

1920*1080@25fps

1536*1536@25fps

2688*1520@25fps

Video Mode

360° 3D VR Mode

Split   Screen

1/2/4

Electronic   PTZ

Yes

Smart Phone

iPhone, Android

Camera Features

Day/Night

Color/ B&W (Auto ICR )

BLC

Support

Support

Support

Support

AGC

Support

Support

 Support

Support

Motion Detection

Smart PIR Sensor (Sensitivity Editable)

General

Housing

Plastic for Indoor Use

Bracket

YES

Operation Temperature

-20℃ ~ +55℃ RH95% Max

Storage Temperature

-25℃ ~ +60℃ RH95% Max

Power Type

AC220 -240V

Dimension

80L)*80(W)*138(H)mm

Weight

500g
