NVR System

Type

36CH NVR

Compression Method

H.265+/ H.265/ H.264

Operating System

Embedded LINUX

HDD

4 SATA, MAX 8TB Each

Intelligent Function

Support   full channel 9 kind of smart analysis functions with IPC including: Line   Crosssing, Area Detection, Object Left/Lost, Traget Count, Cross Border   detection, Sound Abnormal, Fire Detection, Video Diagnostics, Face Detection,   Scence Change, LPRt)

Display & Recording

Video Preview

36CH*8MP@25fps

36CH*5MP@30fps and Below

Preview Split

1/4/9/16/36 Screen

Input Bandwidth

288Mbs

Playback

16ch/9ch/4ch   Synchronized Playback

Search Mode

Time, Date, Alarm, Motion Detection, Exact Search

Playback Mode

Normal Play, Fast Forward, Fast Rewind,

Frame by Frame, Zoom In /Out

Video | Alarm | Audio

Video Output

1x HDMI(3840x2160),1x VGA(1920x1080)

Audio IN/OUT

1:2

Two Way Audio

Yes

Alarm IN/OUT

/

Motion Detection

YES

Trigger Events

Recording,  Email, Screen Tips, Buzzer

Email Alarm

Send Image   to The Designated E-mail

Network

Interface

RJ45 Port / 10M / 100M/1000M  Adaptive

IP Address ; TCP/IP, DHCP, UDP, SMTP, NTP

Protocol

UPnP (Plug & Play), SNMP (Simple Network   Management), NTP (Network Timekeeping), SADP (Device Network Search), SMTP   (Mail Service), NFS (Access NAS), Iscsi (IP SAN Application), PPPoE (Dial-up   Internet access), DHCP (automatically obtain IP address)

VMS Software

Support

Cloud Support

iCloud Software One‐Click Online; Support IE Firefox

Google Chrome Mac OS Safari

Language

18 kinds of Languages

Smart Phone

Iphone, Ipad, Android, Android Pad

PC System

Supports Windows 7 and Above Computer Client, Cupports   Apple MAC Computer Client

POE Port

/

General

Voltage

DC 12V /6A (Internal Adapter)

USB Port

1 USB3.0 + 2 USB2.0

RS485

YES

PTZ

Control PTZ device by network

Size

432(W) ×90(H) ×440(L)mm

Weight

7.4 Kgs (Without HDD)
