NVR System

Type

32CH NVR

Compression Method

H.265+/ H.265/ H.264

Operating System

Embedded LINUX

HDD

4 SATA, MAX 8TB Each

Intelligent Function

Support   smart analysis with smart IPC （Line Crossing, Area Detection, Object   Left/Lost, Target Count)

Display & Recording

Video Preview

16CH*4MP@30fps

32CH*1080P@30fps and Below

Preview Split

1/4/9/16/25/36 Screen

Input Bandwidth

80Mbs

Playback

4CH 1080P

1CH 4K

Search Mode

Time, Date, Alarm, Motion Detection, Exact Search

Playback Mode

Normal Play, Fast Forward, Fast Rewind,

Frame by Frame, Zoom In /Out

Video | Alarm | Audio

Video Output

1x HDMI(3840x2160),1x VGA(1920x1080)

Audio IN/OUT

1:1 Network   Video: Network Audio

Alarm IN/OUT

/

Motion Detection

YES

Trigger Events

Recording,  Email, Screen Tips, Buzzer

Email Alarm

Send Image   to The Designated E-mail

Network

Interface

RJ45 Port / 10M / 100M/1000M  Adaptive

IP Address ; TCP/IP, DHCP, UDP, SMTP, NTP

Protocol

UPnP (Plug & Play), SNMP (Simple Network   Management), NTP (Network Timekeeping), SADP (Device Network Search), SMTP   (Mail Service), NFS (Access NAS), Iscsi (IP SAN Application), PPPoE (Dial-up   Internet access), DHCP (automatically obtain IP address)

VMS Software

Support

Cloud Support

iCloud Software One‐Click Online; Support IE Firefox

Google Chrome Mac OS Safari

Language

18 kinds of Languages

Smart Phone

Iphone, Ipad, Android, Android Pad

PC System

Supports Windows 7 and Above Computer Client, Cupports   Apple MAC Computer Client

POE Port

/

General

Voltage

DC 12V /3A

USB Port

2 USB2.0

RS485

Yes

PTZ

Control PTZ device by network

Size

350(W) ×68(H) ×240(L)mm/Single; 5pcs/Carton

Weight

2.9 Kgs (Without HDD)
