Chipset

Image Sensor

1/3" F37

1/3" OV4689

Main processor

FH8626V100

FH8550

Resolution

1080P

1080P

Effective Pixels

  1920(H)*1080(V)

  2542(H)*1600(V)

Compression

H.264/JPEG/AVI/MJPEG

H.264/JPEG/AVI/ MJPEG

TV System

PAL/NTSC Adjustable

Pan

0°-360°

Tilt

0°-100°

Auto   Tracking

Yes

S/N Ratio

≥52dB

Lens

Focus Length

Dual: 3.6mm(120°Wide-Angle)

12mm (45°Telephoto Lens)

Dual: 3.6mm(120°Wide-Angle)

12mm (45°Telephoto Lens)

Focus Control

10X    (Physical Zoom: 3.3X,Digital Zoom: 3X)

10X    (Physical Zoom: 3.3X,Digital Zoom: 3X)

Lens Type

Fixed

Fixed

Pixels

2MP

4MP

Night Vision

Infrared LED

4pcs White   Led + 4pcs IR Array

Infrared Distance

20M

IR Status

Under 10 Lux By CDS

IR Power On

CDS Auto Control

Network

WIFI

2.4GHz WiFi (IEEE 802.11 b/g/n)

RJ45 Access

Yes

Antenna

Built-in

P2P

YES

OS Require

iOS (V10.0 or Above) or Android (V5.0 or   Above)

SD Card

                                                        Support Max 128GB SD-card

Cloud Storage

                                                                    YES

Audio Input

Internal Microphone (38dB)

Pickup Range

5 Meters

Audio Output

Internal Speaker (38dB)

Audio Type

Two-way Audio with Noise Cancellation

Video Quality

1920*1080@25fps

2542*1600@25fps

Video Mode

Manual Video; Alarm Video

Smart Phone

iPhone, Android

Camera Features

Day/Night

Color/ B&W (Auto ICR )

BLC

Support

Support

AGC

Support

 Support

Motion Detection

Face Detection/ Humanoid Detection

General

Housing

IP66 for outdoor Use

Bracket

YES

Operation Temperature

-20℃ ~ +55℃ RH95% Max

Storage Temperature

-25℃ ~ +60℃ RH95% Max

Power Type

DC 5V 2A

Dimension

220(L)*220(W)*210(H)mm

Weight

2000g
