Chipset

Image Sensor

1/2.8"SONY CMOS

1/2.7"Sony CMOS Optional

Horizontal Resolution

2MP

5MP

Compression

H.265

H.265

TV System

PAL/NTSC Adjustable

S/N Ratio

≥50dB

AI Auto Tracking

Detection Type

Humanoid Detection

Tracking Mode

3D Auto-Tracking

Tracking Distance

5M ~ 45M

Tracking Time

8S ~ 40S (Optional)

Human Moving Speed

3~12KM/H

Alarm Mode

Sound and Light Alarm ; Message Pushed by Phone APP

Intercom

Voice Talk-back

PIR Detction

Support

Lens

Focus Length

F=4.7-94mm

F=4.7-94mm

Focus Control

20x Zoom Motorized

20x Zoom Motorized

Pixels

2M Pixels

5M Pixels

Night Vision

White LED

LED: 8pcs   Warm Light

Light Distance

90M

Night Vision

FULL Color at Night

PTZ Features

Pan Rotation Range

0°~360°

Pan Rotation Speed

0~200°/S

Tilt Rotation Range

0°~93°

Tilt Rotation Speed

0~100°/S

Auto Flip

Horizontal 360°, Vertical 93°

Preset Points

128 of preset( Dwell Time 01-60s Interval Available)

A-B Scan

User Programmable (Scan Speed 1-64 Levels Setting Available   )

360° Scan

Support

Guard Tours

4 Groups (Max.16 Points)

Communication Model

RJ45  (WIFI/4G   Optional)

Network

Network Protocol

TCP/IP , TTP ,    NTP , IGMP , DHCP , UDP , SMTP , RTP , RTSP , ARP , DDNS , DNS , PPPoE   , P2P

ONVIF

Standard ONVIF 2.4

Software Control

IE, CMS, Management Platform, P2P

Mobile View(Optional)

Android , iPhone

Network Interface

Built-in RJ45 Network Interface, Support 10M/100M IP   DATA

Compatibility 1

Working with HIKVISION/ DAHUA/ XM/ TVT/ Video Park/   AEVISION NVRs and so on

Compatibility 2

Working with CMS(XM)/ UC2/ Milestone/ NUUO and AXXON Platform   and Other Platforms

General

Housing

Metal, IP66

Bracket

YES

IR Cut Filter

YES

Operation Temperature

-30℃ ~ +50℃ RH95% Max

Storage Temperature

-40℃ ~ +60℃ RH95% Max

Power Source

DC12V, 4A /  AC24V,3A Optional

Power Consumption

≤ 25W

Dimension

288(L)*220(W) 220(H) mm

Weight

2.8 Kgs
