Chipset

Chipset Solution

GK7605V100+SC5339

GK7205V300+ SONY IMX335

NT98566+SC8239

Horizontal Resolution

5MP

5MP

8MP

Compression

H.265

H.265

H.265

TV System

PAL/NTSC Adjustable

S/N Ratio

≥50dB

Lens

Focus Length

F=4.7mm~94mm

F=4.7mm~94mm

F=4.7mm~94mm

Focus Control

20X Zoom

20X Zoom

20X Zoom

Pixels

5M Pixels

5M Pixels

8M Pixels

Night Vision

Infrared LED

IR LED:6pcs IR Array

Infrared Distance

80M

Auto Control IR LED

PWM

PTZ Features

Pan Rotation Range

0°~360°

Pan Rotation Speed

80°/S (High Speed) or 45°/S   (Medium Speed) Optional

Tilt Rotation Range

0°~90°

Tilt Rotation Speed

40°/S (High Speed) or 30°/S   (Medium Speed) Optional

Auto Flip

Horizontal 180°, Vertical 93°

Preset Points

220 of preset( Dwell Time   01-60s Interval Available)

A-B Scan

User Programmable (Scan Speed   1-64 Levels Setting Available )

360° Scan

Support

Guard Tours

3 Groups (Max.16 Points)

Communication Model

RJ45  (WIFI/4G Optional)

Network

Network Protocol

TCP/IP , TTP ,  NTP , IGMP , DHCP , UDP , SMTP , RTP , RTSP   , ARP , DDNS , DNS , PPPoE , P2P

ONVIF

Standard ONVIF 2.4

Software Control

IE, CMS, Management Platform,   P2P

Mobile View(Optional)

Android, i-Phone

Network Interface

Built-in RJ45 Network Interface,   Support 10M/100M IP DATA

Compatibility 1

Working with HIKVISION/ DAHUA/ XM/   TVT/ Video Park/ AEVISION NVRs and so on

Compatibility 2

Working with CMS(XM)/ UC2/ Milestone/   NUUO and AXXON Platform and Other Platforms

General

Housing

Metal, IP66

Bracket

YES

IR Cut Filter

YES

Operation Temperature

-30℃ ~ +50℃ RH95% Max

Storage Temperature

-40℃ ~ +60℃ RH95% Max

Power Source

DC12V±10%, 3A/4A

Power Consumption

≤ 25W

Dimension

295(L)*280(W) *170(H) mm

Weight

4.5Kgs
