Features:
Waterproof Outdoor IR Bullet Camera
3.6mm/2.8mm Fixed Lens
IR LED: 36pcs F5
30M IR Range
Water Resistant Rate: IP66
Microphone Audio, POE Optional
ONVIF 2.4
Model NO. | IPC-HBIF33M20SM | IPC-HBIF33M50SM | IPC-HBIF33M60GM | IPC-HBIF33M80SM | |
Chipset | |||||
Image Sensor | SONY IMX307 | SONY IMX335 | GC5603 | SONY IMX415 | |
Main processor | MSC335 | MSC30KQ | MSC30KD | MSC328Q | |
Resolution | 1080P | 5MP | 6MP | 8MP | |
Effective Pixels | 1920(H)*1080(V) | 2592(H)*1944(V) | 3072(H)*2048(V) | 3840(H)*2160(V) | |
Compression | H.264/H.265/ JPEG/AVI/MJPEG | ||||
TV System | PAL/NTSC Adjustable | ||||
Electronic Shutter Time | Auto: PAL 1/25-1/10000Sec; NTSC 1/25-1/10000Sec | ||||
S/N Ratio | ≥52dB | ||||
Scanning System | Progressive | ||||
Video Output | Network | ||||
Lens | |||||
Focus Length | 3.6/2.8/6mm | 3.6/2.8/6mm | 3.6/2.8/6mm | 3.6/2.8/6mm | |
Focus Control | Fixed | Fixed | Fixed | Fixed | |
Lens Type | Fixed | Fixed | Fixed | Fixed | |
Pixels | 2MP | 5MP | 6MP | 8MP | |
Night Vision | |||||
Infrared LED | IR LED: 30pcs F5 | ||||
Infrared Distance | 25M | ||||
IR Status | Under 10 Lux By CDS | ||||
IR Power On | CDS Auto Control | ||||
Network | |||||
Ethernet | RJ-45 (10/100Base-T) | ||||
Protocol | TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,NTP,SMTP | ||||
ONVIF | Support ONVIF 2.4 | ||||
P2P | YES, Support QR Code | ||||
POE | YES | ||||
WIFI | N/A | ||||
TF Card | N/A | ||||
Video Bit Rate | Constant Bit Rate, Variable Bit Rate (16kbps~8000kbps) | ||||
Video Type | Complex Stream/ Video Stream | ||||
Audio Compression | G.711U (Optional) | ||||
Main Stream 1 | 1920*1080@30fps | 2592*1944@25fps | 3072*2048@25fps | 3840*2160@20fps | |
Main Stream 2 | 3MP@25fps | 2048*1520@30fps | 2560×1440/2304×1296@30fps | 3072*1728@25fps | |
Main Stream 3 | 720P/D1@30fps | 1920*1080@30fps | 1920×1080/1280×720@60fps | 2592*1944/2560*1440/1080P@30fps | |
Sub Stream 1 | 640*360@25fps | 720*480@30fps | 720*480@30fps | 720*480@30fps | |
Sub Stream 2 | VGA/D1/CIF@25fps | 640*360@30fps | 640*360/VGA/D1@30fps | 640*360@30fps | |
Tri Stream | 1920*1080@30fps | 2592*1944@25fps | 3072*2048@25fps | 3840*2160@20fps | |
IE Brower | IE8-11, Google Chrome, Firefox, Safari, Mac Safari | ||||
Smart Phone | i-Phone, iPad, Android, Android Pad | ||||
Intelligent Analysis | Human Detection, motion detection | Human Detection,Vehicle Detection, motion detection | |||
Day/Night | Color/ B&W (IR-CUT ) | ||||
Image Config | Saturation/Brightness/Contrast /Sharpness, Mirror, 3D NR , White Balance, FLK(Flicker Control) | ||||
Corridor Pattern | Support | ||||
Defog Mode | Support | ||||
BLC | Support | ||||
HDR | Support | ||||
WDR | Support | ||||
Motion Detection | Support | ||||
Privacy Masking | 3 Rectangular Zone | ||||
Recording Mode | NVR/NAS/CMS/Web | ||||
Language | Chinese Simplified, Chinese Traditional, English, Russian, Ukrainian, German, Italian, Turkish, Hrvatski, Portuguese, Polski, Korean, Japanese, Arabic | ||||
General | |||||
Housing | Metal ,IP66 | ||||
Anti-cut Bracket | YES | ||||
IR Cut Filter | YES | ||||
Operation Temperature | -10℃ ~ +50℃ RH95% Max | ||||
Storage Temperature | -20℃ ~ +60℃ RH95% Max | ||||
Power Source | DC12V±10%, 600mA | ||||
Dimension | 71(W)*72(H)*188(L)mm | ||||
Weight | 550g |
