Features:
HD Vehicle Camera with Dual Sensors
Front Lens: 2.8mm(Default)/3.6mm
Back Lens: 3.6mm(Default)/2.8mm
IR LED: 6pcs IR SMD,IR10M
Microphone +Speaker Intercom Audio
4IN1 AHD/TVI/CVI/CVBS
Dual Aviation Output Plugs
4IN-HVIF04M10 | 4IN-HVIF04M13 | 4IN-HVIF04M20 | 4IN-HVIF04M50 | 4IN-HVIF04M80 | |
Video Output Mode | AHD/CVI/TVI/CVBS | AHD/CVI/TVI/CVBS | AHD/CVI/TVI/CVBS | AHD/CVI/TVI/CVBS | AHD/CVI/TVI/CVBS |
Chipset | |||||
Dual Image Sensor | 1/4" CMOS *2 | 1/3" CMOS *2 | 1/2.8” CMOS *2 | 1/2.7" CMOS *2 | 1/2.5" CMOS *2 |
DSP | XM310 *2 | V20E *2 | FH8536/NVP2441 *2 | FH8538/NVP2477 *2 | FH8556/NVP2481 *2 |
Image Resolution | 1.0MP | 1.3MP | 2.0MP | 5.0MP | 8.0MP/4K |
Effective Pixels | 1280*720 | 1305*977 | 1920*1080 | 2592*1944 | 3840*2160 |
TV System | PAL/NTSC | ||||
Electronic Shutter | 1/25s~1/50,000s , 1/30s~1/60,000s | ||||
S/N Ratio | ≥50dB | ||||
Scanning System | Progressive Scan | ||||
Lens | |||||
Front Lens | 2.8mm(120°)/3.6mm | 2.8mm(120°)/3.6mm | 2.8mm(120°)/3.6mm | 2.8mm(120°)/3.6mm | 2.8mm(120°)/3.6mm |
Back Lens | 3.6mm(90°)/2.8mm | 3.6mm(90°)/2.8mm | 3.6mm(90°)/2.8mm | 3.6mm(90°)/2.8mm | 3.6mm(90°)/2.8mm |
Lens Type | Fixed | Fixed | Fixed | Fixed | Fixed |
Pixels | 2M Pixels | 2M Pixels | 2M Pixels | 5M Pixels | 8M Pixels |
Night Vision | |||||
Infrared LED | IR LED: 6pcs IR SMD | ||||
Infrared Distance | 10M | ||||
IR Status | Under 10 Lux by CDS | ||||
IR Power On | CDS Auto Control | ||||
Camera Features | |||||
Day/Night | YES | YES | YES | YES | YES |
OSD Menu Language | Eng/Chin1/Chin2/Pycc/Espa/Fran/Pol/Ital/Port/Japan | Eng/Chin1/Chin2/Pycc/Espa/Fran/Pol/Ital/Port/Japan | Eng/Chin1/Chin2/Pycc/Espa/Fran/Pol/Ital/Port/Japan | Eng/Chin1/Chin2/Pycc/Espa/Fran/Pol/Ital/Port/Japan | |
Gain Control | AUTO | AUTO | AUTO | AUTO | AUTO |
Noise Reduction | DNR | 3DNR | 3DNR | 3DNR | 3DNR |
Picture Adjustment | YES | YES | YES | YES | YES |
WDR | DWDR,>80dB | Super WDR,>120dB | Super WDR,>120dB | ||
OSD Support | Optional | YES | YES | YES | YES |
UTC | YES | YES | YES | YES | YES |
General | |||||
Housing | Plastic | ||||
Bracket | YES(Adjustable Bracket -45° ~ +45°) | ||||
IR Cut Filter | Yes | ||||
Operation Temperature | -20℃ ~ +60℃ RH95% Max | ||||
Storage Temperature | -25℃ ~ +65℃ RH95% Max | ||||
Power Source | DC12V±10%, 450mA | ||||
Dimension | 127mm(L)*88(W)*40mm(H) | ||||
Weight | 200g | ||||
