Video Output Mode

AHD/CVI/TVI/CVBS

AHD/CVI/TVI/CVBS

AHD/CVI/TVI/CVBS

AHD/CVI/TVI/CVBS

AHD/CVI/TVI/CVBS

Chipset

Image Sensor

1/4" CMOS H62

1/3"Aptina AR0130

/2.9"SONY IMX323

1/2.9"SONY IMX307

1/2.8"SONY IMX327

DSP

V20E

NVP2433

V30E

NVP2441

V30E

Image Resolution

720P/ 960H

960P / 960H

1080P / 960H

1080P/960H

1080P/960H

Effective Pixels

1280*720

1920*960

1920*1080

1920*1080

1920*1080

TV System

PAL/NTSC

Electronic Shutter

1/25s~1/50,000s , 1/30s~1/60,000s

S/N Ratio

≥50dB

Scanning System

Progressive Scan

Lens

Focus Length

2.8/3.6mm

2.8/3.6mm

2.8/3.6mm

2.8/3.6mm

2.8/3.6mm

Focus Control

Fixed

Fixed

Fixed

Fixed

Fixed

Lens Type

Fixed

Fixed

Fixed

Fixed

Fixed

Pixels

2M Pixels

2M Pixels

2M Pixels

2M Pixels

2M Pixels

Night Vision

Infrared LED

IR LED: F5 x 12 pcs

Infrared Distance

10M

IR Status

Under 10 Lux by CDS

IR Power On

CDS Auto Control

Camera Features

Day/Night

YES

YES

YES

YES

YES

OSD Menu Language

Optional

YES

YES

YES

YES

Gain Control

AUTO

AUTO

AUTO

AUTO

AUTO

Noise Reduction

DNR

3DNR

3DNR

3DNR

3DNR

Picture Adjustment

YES

YES

YES

YES

YES

WDR

YES

YES

YES

YES

YES

OSD Support

Optional

YES

YES

YES

YES

UTC

YES

YES

YES

YES

YES

General

Housing

Metal

Bracket

YES

IR Cut Filter

YES

Operation Temperature

-10℃ ~ +50℃ RH95% Max

Storage Temperature

-20℃ ~ +60℃ RH95% Max

Power Source

DC12V±10%, 250mA

Dimension

77(L)*77(W)*76(H)mm

Weight

250g
