Features:
9CH H.265 Smart AI Inside Face Recognition NVR
2PCS 2MP Face Recognition Cameras &
2PCS 3MP Humanoid Detection Cameras
Compressed Format: H.265/H.264
8CH 5MP and Below
Video Output: 1xHDMI,1xVGA
HDD: 1 SATA, MAX 6TB
9CH H.265 Smart AI Inside Face Recognition NVR
Support 4PCS 2MP Face Recognition Cameras
Support 8PCS 3MP Humanoid Detection Cameras
Compressed Format: H.265/H.264
8CH 5MP and Below
Video Output: 1xHDMI,1xVGA
HDD: 1 SATA, MAX 6TB
Model NO. | IVR-V08H1M5009 |
NVR System | |
Type | 9CH NVR |
Compression Method | H.265/ H.264 |
Operating System | Embedded LINUX |
Operation Interface | Win Style |
HDD | 1 SATA, MAX 6TB |
Store Backup | USB Disk |
Smart Function | Human Detection and Capture, Region Intrusion, Trip-line Detection, Human video retrieval, Real-time face comparison, Database management, Blacklist control, Stranger alarm, Wander and stay, Traffic statistics |
Display & Recording | |
Video Preview | 9CH*5MP@30fps 9CH*1080P@30fps |
Preview Split | 1/4/9 Screen |
Input Bandwidth | 80 Mbps |
Recording Mode | All-day/Day/Night/Customization |
Playback | 1CH 5MP 2CH 3MP 4CH 1080P |
Video Type | Regular Video, Face Retrieval, Video Loss, Human Detection |
Search Mode | Time, Date, Alarm, Motion Detection, Exact Search |
Playback Mode | Normal Play, Fast Forward, Fast Rewind, Frame by Frame, Zoom In /Out |
Video | Alarm | Audio | |
Video Output | 1x HDMI(3840x2160),1x VGA(1920x1080) |
Output Resolution | 1920*1080/1280*1024/1024*768 |
Audio IN/OUT | N/A |
Alarm IN/OUT | N/A |
Motion Detection | YES |
Trigger Events | Recording, Email, Screen Tips, Buzzer, Light, APP Push |
Email Alarm | Send Image to The Designated E-mail |
Network | |
Interface | RJ45 Port / 10M / 100M Adaptive IP Address ; TCP/IP, DHCP, UDP, SMTP, NTP |
Protocol | UPnP (Plug & Play), SNMP (Simple Network Management), NTP (Network Timekeeping), SADP (Device Network Search), SMTP (Mail Service), NFS (Access NAS), iSCSI (IP SAN Application), PPPoE (Dial-up Internet access), DHCP (automatically obtain IP address) |
VMS Software | Support |
Browser | IE/Chrome/Firehox/Safari etc |
Language | English/Chinese |
Smart Phone | Iphone, Ipad, Android, Android Pad |
PC System | Supports Windows 7 and Above Computer Client, Cupports Apple MAC Computer Client |
POE Port | / |
General | |
Voltage | DC 12V /4A <10W (Without Hard Disk) |
USB Port | 2 USB2.0 |
PTZ | Currently None |
Size | 220(W) ×44(H) ×260(L)mm/Single; 10pcs/Carton |
Weight | 1.5 Kgs (Without HDD) |
Smart AI Inside Face Recognition Camera
Compressed Format: H.265+/H.265
Lens: 6mm
IR LED: F5 x 36pcs
30M IR Range
Black Acrylic Glass
Water Resistant Rate:IP66
ONVIF 2.4
Model No. | IGC-S28H1M20S |
Chipset | |
Resolution | 2.0M/1080P |
Sensor | 1/2.8" Sony CMOS |
Effect Pixel | 1920(H)x1080(V) |
Scanning method | Line-by-line Scan |
Shutter time | 1/25s~1/10000s; |
Min Illumination | Color:0.0001Lux @F1.2 |
White&Black:0.0001Lux @F1.2 | |
S/N Ratio | ≥50dB(AGC OFF) |
Wide Dynamic Range | >120dB |
Digital Noise Reduction | 3D Digital Noise Reduction |
Privacy cover | Up to 4 Privacy Area |
Lens | 6mm |
Video Parameters | |
Video compression | H.265+/H.264/MJPEG |
Video resolution | Main stream 1080P(1920×1080)/720P(1280×720) |
Sub stream D1(704×576)/VGA(640*480)/QVGA(320×240) | |
Video Frame | 1-25(30)fps |
Video Bit rate | 128Kbps~4096Kbps |
Audio parameter | |
Audio compression format | G.711a/ G.711u/G.726 |
Audio Mount | Support |
Smart Function | |
Smart Application | Face Detection,Face Capture, Face Recognition,Quick Register,Face Alarm,Face Retrieval,Face Analysis,Traffic Statistics |
Capture Face | 3pcs Face/Frame(10pcs Optional) |
Network parameters | |
Network interface | 1 RJ45 10M/100M Adaptive Ethernet port |
Network Protocol | IPv4, HTTP, TCP/IP, UDP, RTP, RTCP, UPNP, RTSP, SMTP, NTP,DHCP, DNS, PPPOE, DDNS, FTP |
Access Standard | ONVIF |
Browser | IE/Chrome/Firehox/Safari etc |
APP | For Android and IOS Apple |
Support Users | Max 6 Users (IGC)/ Max 4 Users (Onvif) at the same time |
User Quantity | 10 of Users |
General Parameters | |
Housing | White Aluminium |
Power supply | DC12V / 2A POE(Optional) |
Power consumption | <14W |
Operate Conditions | "30℃~60℃,,Humidity 95% or less than (non-condensing) |
Waterproof | IP66 |
Infrared LED | IR LED: ￠5X36pcs |
IR Distance | 30m |
Dimensions | 70(W)*70(H)*220(L)mm |
Device Weight | 650g |
Bracket | 3-Axis |
Smart AI Inside Humanoid Detection Camera
Compressed Format: H.265+/H.265
Lens: 6mm
IR LED: F5 x 36pcs
30M IR Range
Black Acrylic Glass
Water Resistant Rate:IP66
ONVIF 2.4
Model No. | IGC-S39H1M30S |
Chipset | |
Resolution | 3 MP |
Sensor | 1/2.8" Sony CMOS |
Effect Pixel | 3MP |
Scanning method | Line-by-line Scan |
Shutter time | 1/25s~1/10000s; |
Min Illumination | Color:0.0001Lux @F1.2 |
White&Black:0.0001Lux @F1.2 | |
S/N Ratio | ≥50dB(AGC OFF) |
Wide Dynamic Range | >120dB |
Digital Noise Reduction | 3D Digital Noise Reduction |
Privacy cover | Up to 4 Privacy Area |
Lens | 6mm |
Video Parameters | |
Video compression | H.265+/H.264/MJPEG |
Video resolution | Main stream 1080P(1920×1080)/720P(1280×720) |
Sub stream D1(704×576)/VGA(640*480)/QVGA(320×240) | |
Video Frame | 1-25(30)fps |
Video Bit rate | 128Kbps~4096Kbps |
Audio parameter | |
Audio compression format | G.711a/ G.711u/G.726 |
Audio Mount | Support |
Smart Function | |
Smart Application | Humanoid Detection, Humanoid Capture, Quick Register, Alarm, Retrieval, Smart Analysis, Traffic Statistics |
Network parameters | |
Network interface | 1 RJ45 10M/100M Adaptive Ethernet port |
Network Protocol | IPv4, HTTP, TCP/IP, UDP, RTP, RTCP, UPNP, RTSP, SMTP, NTP,DHCP, DNS, PPPOE, DDNS, FTP |
Access Standard | ONVIF |
Browser | |
APP | For Android and IOS Apple |
Support Users | Max 6 Users (IGC)/ Max 4 Users (Onvif) at the same time |
User Quantity | 10 of Users |
General Parameters | |
Housing | White Aluminium |
Power supply | DC12V / 2A POE(Optional) |
Power consumption | <14W |
Operate Conditions | "30℃~60℃,,Humidity 95% or less than (non-condensing) |
Waterproof | IP66 |
Infrared LED | IR LED: ￠5X36pcs |
IR Distance | 30m |
Dimensions | 70(W)*70(H)*220(L)mm |
Device Weight | 650g |
Bracket | 3-Axis |
Please enter your inquiry details such as model no., lens, color,quantity,ect .
