NVR   System

Type

9CH   NVR

Compression   Method

H.265/   H.264

Operating   System

Embedded   LINUX

Operation   Interface

Win   Style

HDD

1   SATA, MAX 6TB

Store Backup

USB   Disk

Smart  Function

Human Detection and Capture, Region Intrusion, Trip-line   Detection, Human video retrieval, Real-time face comparison, Database   management, Blacklist control, Stranger alarm, Wander and stay, Traffic   statistics

Display   & Recording

Video   Preview

9CH*5MP@30fps

9CH*1080P@30fps

Preview   Split

1/4/9   Screen

Input   Bandwidth

80 Mbps

Recording   Mode

All-day/Day/Night/Customization

Playback

1CH 5MP

2CH 3MP

4CH   1080P

Video   Type

Regular   Video, Face Retrieval, Video Loss, Human Detection

Search   Mode

Time,   Date, Alarm, Motion Detection, Exact Search

Playback   Mode

Normal   Play, Fast Forward, Fast Rewind,

Frame   by Frame, Zoom In /Out

Video   | Alarm | Audio

Video   Output

1x   HDMI(3840x2160),1x VGA(1920x1080)

Output   Resolution

1920*1080/1280*1024/1024*768

Audio   IN/OUT

N/A

Alarm   IN/OUT

N/A

Motion   Detection

YES

Trigger   Events

Recording,    Email, Screen Tips, Buzzer, Light, APP Push

Email   Alarm

Send   Image to The Designated E-mail

Network

Interface

RJ45   Port / 10M / 100M  Adaptive

IP   Address ; TCP/IP, DHCP, UDP, SMTP, NTP

Protocol

UPnP   (Plug & Play), SNMP (Simple Network   Management), NTP (Network   Timekeeping), SADP (Device Network Search), SMTP   (Mail Service), NFS   (Access NAS), iSCSI (IP SAN Application), PPPoE (Dial-up   Internet   access), DHCP (automatically obtain IP address)

VMS   Software

Support

Browser

IE/Chrome/Firehox/Safari   etc

Language

English/Chinese

Smart   Phone

Iphone,   Ipad, Android, Android Pad

PC   System

Supports   Windows 7 and Above Computer Client, Cupports   Apple MAC Computer   Client

POE   Port

/

General

Voltage

DC 12V   /4A

<10W   (Without Hard Disk)

USB   Port

2   USB2.0

PTZ

Currently   None

Size

220(W)   ×44(H) ×260(L)mm/Single; 10pcs/Carton

Weight

1.5   Kgs (Without HDD)

Chipset

Resolution

2.0M/1080P

Sensor

1/2.8" Sony CMOS

Effect Pixel

1920(H)x1080(V)

Scanning method

Line-by-line Scan

Shutter time

1/25s~1/10000s;

Min Illumination

Color:0.0001Lux @F1.2

 White&Black:0.0001Lux @F1.2

S/N Ratio

≥50dB(AGC OFF)

Wide Dynamic Range

>120dB

Digital Noise Reduction

3D Digital Noise Reduction

Privacy cover

Up to 4 Privacy Area

Lens

6mm

Video Parameters

Video compression

H.265+/H.264/MJPEG

Video resolution

Main stream  1080P(1920×1080)/720P(1280×720)

 Sub   stream D1(704×576)/VGA(640*480)/QVGA(320×240)

Video Frame

1-25(30)fps

Video Bit rate

128Kbps~4096Kbps

Audio parameter

Audio compression format

G.711a/ G.711u/G.726

Audio Mount

Support

Smart Function

Smart Application

Face Detection,Face Capture,   Face Recognition,Quick

Register,Face Alarm,Face   Retrieval,Face Analysis,Traffic Statistics

Capture Face

3pcs Face/Frame(10pcs   Optional)

Network parameters

Network interface

1 RJ45 10M/100M Adaptive Ethernet port

Network Protocol

IPv4, HTTP, TCP/IP, UDP, RTP, RTCP, UPNP,   RTSP, SMTP, NTP,DHCP, DNS,   PPPOE, DDNS, FTP

Access Standard

ONVIF

Browser

IE/Chrome/Firehox/Safari etc

APP

For Android and IOS Apple

Support Users

Max 6 Users (IGC)/ Max 4 Users (Onvif) at   the same time

User Quantity

10 of Users

General Parameters

Housing

White Aluminium

Power supply

DC12V / 2A POE(Optional)

Power consumption

<14W

Operate Conditions

"30℃~60℃,,Humidity 95% or   less than (non-condensing)

Waterproof

IP66

Infrared LED

IR LED: ￠5X36pcs

IR Distance

30m

Dimensions

70(W)*70(H)*220(L)mm

Device Weight

650g

Bracket

3-Axis
