Video Output Mode

AHD/CVI/TVI/CVBS

AHD/CVI/TVI/CVBS

AHD/CVI/TVI/CVBS

Chipset

Image Sensor

1/3"SONY 2.1MP CMOS

1/2.9"OmniVision CMOS

1/2.8"OmniVision CMOS

Horizontal Resolution

2MP

4MP

5MP

TV System

PAL/NTSC

S/N Ratio

≥50dB

Lens

Focus Length

F=5~50mm/ 4.7mm~94mm/   4.6mm~165mm

F=5~50mm/ 4.7mm~94mm/   4.6mm~165mm

F=5~50mm/   4.7mm~94mm/ 4.6mm~165mm

Focus Control

10X/20X/36X   Optical Zoom

10X/20X/36X   Optical Zoom

10X/20X/36X   Optical Zoom

Pixels

2M Pixels

5M Pixels

5M Pixels

Night Vision

Infrared LED

IR LED: 42Mil IR Array x 6pcs

Infrared Distance

120M

Auto Control IR LED

PWM

PTZ Features

Pan Rotation Range

0°~360°

Pan Rotation Speed

80°/S (High Speed) or 45°/S   (Medium Speed) Optional

Tilt Rotation Range

0°~90°

Tilt Rotation Speed

40°/S (High Speed) or 30°/S   (Medium Speed) Optional

Auto Flip

Horizontal 180°, Vertical 93°

Preset Points

220 of preset( Dwell Time   01-60s Interval Available)

A-B Scan

User Programmable (Scan Speed   1-64 Levels Setting Available )

360° Scan

Support

Guard Tours

3 Groups (Max.16 Points)

Communication Model

RS485 (+/-) / Coaxial Cable

General

Housing

Metal, IP66

Bracket

YES

IR Cut Filter

YES

Operation Temperature

-30℃ ~ +50℃ RH95% Max

Storage Temperature

-40℃ ~ +60℃ RH95% Max

Power Source

DC12V±10%, 3A/4A

Power Consumption

≤ 25W

Dimension

295(L)*280(W) *170(H) mm

Weight

4.5Kgs
