Chipset

Image Sensor

1/2.8" SC2232 CMOS

1/2.8" OV4689 CMOS

1/2.7" AR0521 CMOS

Horizontal Resolution

2MP

4MP

5MP

Compression

H.264

H.265

H.265

TV System

PAL/NTSC Adjustable

S/N Ratio

≥50dB

Lens

Focus Length

F=4.7mm~94mm

F=4.7mm~94mm

F=4.7mm~94mm

Focus Control

20X Optical Zoom

20X Optical Zoom

20X Optical Zoom

Pixels

2M Pixels/30fps

4M Pixels/30fps

5M Pixels/30fps

Night Vision

Infrared LED

IR LED:   42Mil IR Array x 8pcs

Infrared Distance

150M

Auto Control IR LED

PWM

PTZ Features

Pan Rotation Range

0°~360°

Pan Rotation Speed

80°/S (High Speed) or 45°/S (Medium Speed) Optional

Tilt Rotation Range

0°~90°

Tilt Rotation Speed

40°/S (High Speed) or 30°/S (Medium Speed) Optional

Auto Flip

Horizontal 180°, Vertical 93°

Preset Points

220 of preset( Dwell Time 01-60s Interval Available)

A-B Scan

User Programmable (Scan Speed 1-64 Levels Setting Available   )

360° Scan

Support

Guard Tours

3 Groups (Max.16 Points)

Storage

Support 128GB TF Card

Intercom

Two-way Audio

Communication Model

WIFI / RJ45

4G & WIFI

4G Mode

FDD-LTE, TDD-LTE, WCDMA/HSPA+, TD-SCDMA, GSM/GPRS/EDGE

4G Working Frequency

 LTE B1/B3/B8/B38/B39/B40/B41

WCDMA 2100/900MHz

TD-SCDMA B34/B39

GSM/GPRS/EDGE: 900/ 1800MHz

4G Transmission Speed

FDD-LTE/TDD-LTE: Upward 50M/Down 150Mbps

HSPA+: Upward     5.76M/Down 21Mbps

TD-SCDMA: Upward 2.2Mbps/Down 2.8Mbps

WIFI Protocol

802.11b/g/n

WIFI Working Frequency

2412MHz-2472MHz

WIFI Safe Mode

Open, WPA-PSK, WPA2-PSK

Mobile View(App)

Android, iPhone

General

Housing

Metal, IP66

Bracket

YES

IR Cut Filter

YES

Operation Temperature

-30℃ ~ +50℃ RH95% Max

Storage Temperature

-40℃ ~ +60℃ RH95% Max

Power Source

DC12V±10%, 3A/4A

Power Consumption

≤ 25W

Dimension

320(L)*320(W) *450(H) mm

Weight

5.5Kgs
