Manufacturer

HICO TECH Co.,Limited

NVR System

Type

36CH 4K NVR

Compression Method

H.265+/ H.265/ H.264

Operating System

Embedded LINUX

SATA

4 SATA, MAX 8TB EACH(Excluded HDD)

Display & Recording

Video Preview

1CH*4K@30fps

4CH*1080P@30fps

1CH*5MP+5CH*D1@30fps

1CH*3MP+7CH*D1@30fps

9CH/16CH/25CH/36CH*D1@30fps

Input Bandwidth

288Mbps

Playback

1CH*4K

4CH*1080P

16CH*D1

Search Mode

Time, Date, Alarm, Motion Detection, Exact Search

Playback Mode

Normal Play, Fast Forward, Fast Rewind,

Frame by Frame, Zoom In /Out

Video | Alarm | Audio

Video Output

1x HDMI(3840x2160),1x VGA(1920x1080)

Audio IN/OUT

36CH IPC IN, 1CH IN/ 1CH OUT(TRS Port)

Alarm IN/OUT

2:1

Motion Detection

YES

Human Detection

Support with IPC

Intelligent Function

Support, Optional

Trigger Events

Recording,  Email, Screen tips, Buzzer

Email Alarm

Send Image to The Designated E-mail

Network

Interface Uplink

2 x RJ45 Port / 10M / 100M /1000M Adaptive

IP Address ; TCP/IP, DHCP, UDP, SMTP, NTP

CMS Software

Support

Cloud Support

iCloud Software one‐click online; Support IE Firefox

Google Chrome Mac OS Safari

Language

18 kinds of Languages

Smart Phone

Iphone, Ipad, Android, Android Pad

Wireless Port

N/A

POE Port

N/A

Protocol

RTSP, SLINK（Private Protocol）, ONVIF, I9

General

Voltage

DC 12V /6.25A

Power Consumption

≤ 60W（without HDD）

USB Port

2 USB2.0

PTZ

Control PTZ device by network

RS485

1

Working Temperature/Humidity

     -20°C ~ 55°C / 10﹪-90﹪

Size

440(L)*355(W)*70(H) mm

Weight

6.0 Kgs (Without HDD)
