Features:
XVR:
1 x 8CH H.265 5MP-N Hybrid DVR with HISILICON Chipset
1 x Power Adapter
1 x Mouse
CAMERA:
8 X 5MP IP66 Metal Bullet Camera with 3.6mm lens, IR30M
Accessories:
2 x DC12V 5A Power Adapter with 5 split cable
8 x 20M BNC+DC Cable
HA-KVR5MN1H08BW | |
Type | AHD/TVI/CVI/CVBS Camera |
Resolution | 5MP |
Effective Pixels | 2592*1944 |
TV System | PAL/NTSC Adjustable |
Lens | 3.6mm (Default)/2.8mm/4mm/6mm Optional |
IR Distance | 30M For Bullet |
Noise Reduction | 3DNR |
WDR | DWDR |
IR Cut Filter | Yes |
OSD/UTC | YES |
Waterproof | IP66 |
Operation Temperature | -20ºC ~ +60ºC RH95% Max |
Power | DC12V±10%, 350mA Each |
XVR System | |
8CH 5MP-N 5-IN-1 DVR | |
Compression Method | H.265 |
Main Processor | HISILICON |
Operating System | Embedded LINUX |
Smart Function | Support Face Retrieval Function |
HDD | 1 SATA, MAX 6TB |
Display & Recording | |
Video Input | 8CH |
Encode Capacity | |
Search Mode | Time, Date, Alarm, Motion Detection, Exact Search |
Playback Mode | Normal Play, Fast Forward, Fast Rewind, Frame by Frame, Zoom In /Out |
Playback & Backup | |
Decode Capability | MAX 8CH |
Sync Playback | AHD / TVI / CVI: 1CH 1080P@15fps playback |
Search Mode | ALL, Channel, Manual, Time, Date, Motion Detection |
Playback Functions | Play, Pause, Stop, Fast play, Rewind |
Backup Mode | USB Device/DVD/CD/Network |
Video | Alarm | Audio | |
Video Output | |
Audio | 1CH |
Network | |
Interface | RJ45 Port / 10M / 100M Adaptive IP Address ; TCP/IP, DHCP, UDP, SMTP, NTP |
CMS Software | Support |
Cloud Support | iCloud Software one‐click online; Support IE Firefox Google Chrome Mac OS Safari |
Language | 12 kinds of Languages |
Smart Phone | Iphone, Ipad, Android, Android Pad |
Voltage | DC 12V |
USB Port | 2 USB2.0 |
PTZ | Pelco-D, Pelco-P |
RS485 | YES |
Kits Package Size | 440*260*280mm |
Kits Net Weight | 7.5 Kgs (Without HDD) |
Please enter your inquiry details such as model no., lens, color,quantity,ect .
